Acer Aspire 5739G - Main Module Reassembly Procedure; Replacing the Speaker Modules

Chapter 3 89
2. Remove the six screw caps and screws as shown.
3. Starting at the centre of the top edge, pry the inside of the bezel away from the screen. Work round the edges
to pry the bezel away from the screen as shown.
4. Lift the bezel away from the panel and place it face down above the panel as shown.
Step Size Quantity Screw Type
LCD Bezel M2.5*5 6
