Chapter 3 55
Removing the Home Button Board
1. See “Removing the Inverter Board” on page 53.
2. Remove one (1) securing screw from the Home Button Board.
3. Disconnect one (1) cable from the Home Button Board.
4. Lift the Home Button Board away as shown.
Step Size Quantity Screw Type
Home Button Board 1
To Next Page
