Reassembly Procedure
Replacing the LCD Bracket
1. Replace one side of the LCD Bracket (1), while using the opposite hand to pull the cables through the frame
(2). Make sure the frame is fitted securely on top of the panel.
2. Secure the LCD Panel to the frame using four (4) screws.
1
2
