Chapter 1 7
Left Panel
# Icon Item/ Port Description
1 PCMCIA (PC card) Port Connects to one Type III 16-bit PC card or 32-bit
CardBus PC Card.
2 Eject button Eject the PC cards from the slot.
3 Optical drive Internal optical drive; accepts CDs or DVDs
depending on the optical drive type.
4 Infrared port Interfaces with infrared devices (e.g., infrared
printer, IR-aware computer).
5 Eject button Ejects the optical drive tray from teh drive.
6 LED indicator Lights up when the optical drive is active.
7 Emergency eject slot Ejects the optical drive tray when the computer is
turned off. There is a mechancial eject button on
the CD-ROM or DVD-ROM drive. Simply insert
the tip of a pen or paperclip and push to eject the
tray.
8 Speaker Delivers stereo audio output.
