Acer Extensa 2000 - Hard Disk Drive and LCD Module Procedures

53 Chapter 3
Removing the Hard Disk Drive Module
1. See “Removing the Battery” on page 50.
2. To remove the hard disk drive, pull the hard disk dirve carefully.
3. Then take the hard disk drive out of the main unit.
Disassembling the Hard Disk Drive Module
1. See “Removing the Battery” on page 50.
2. See “Removing the LCD Module” on page 54.
3. Remove the two screws that fasten the HDD holder.
4. Detach the hard disk drive from the HDD holder.
