28 Chapter 1
NOTE: DC-AC inverter is used to generate very high AC voltage, then support to LCD CCFT backlight user,
and is also responsible for the control of LCD brightness. Avoid touching the DC-AC inverter area while
the system unit is turned on.
NOTE: There is an EEPROM in the inverter, which stores its supported LCD type and ID code. If you replace
a new inverter or replace the LCD with a different brand, use Inverter ID utility to update the ID
information.
.
DC-AC LCD Inverter
Item Specification
Vendor & model name Ambit
Input voltage (V) 8 ~ 21V
Input current (mA) 1A (max.)
Output voltage
(Vrms, no load)
1400Vrms
Output voltage
frequency (kHz)
40 ~ 70KHz
Output Current/Lamp 5.5 mA ~ 6.5mA
LCD
Item Specification
Vendor & model name 14.1” AU
B141XN04 V2
15” Hitachi
TX38D85VC1CAB
15” AU B150PG01
SXGA+
Physical Specifications
Display resolution(pixel) 1024(H) x 768(V) 1400(H) x1050(V) 1400(H) x1050(V)
Active area(mm) 285.7(H) x 214.3(V) 304.1(H) x 228.1(V) 304.5 (H) x228.375(V)
Screen Size(inch) 14.1 15.0 15.0
Pixel pitch(mm) 0.279(H)x 0.279(V) 0.297(H)x 0.297(V) 0.2175x 0.2175
Color configuration (Pixel Arrangement) R.G.B. Vertical stripe
Overall dimension(mm) 298.5(W)x226.7(H)x5.
2/5.5(D)
317.3(w)x242.1(H)x6.
0(D)
Weight(g) 445+/-20 580 550
Surface treatment Hard coating (3H),
anti-glare of the front
polarizer
Not show Not show
Power supply(input voltage) 3.6V(max) 3.3V(typ.) 3.6V(max) 3.3V
Response time:Rising time/Falling time 20(typ.)40(max)/
30(typ.)50(max)
30(typ.)50(max)
30(typ.)50(max)
15(typ.)
35(typ.)
Contrast ratio 250 200 250
Support colors 262K 262k 262K
Typical White Luminance 150 180 150
AC Adapter
Item Specification
Vendor & model name Liton
Input Requirements
Maximum input current (A,
@90Vac, full load)
1.5 A @ 110Vac
1.0 A @ 240Vac
Nominal frequency (Hz) 50-60
