Chapter 6
93
PC board
System board 500 MAIN BOARD 55.45B01.001 1
DC-DC/
charger board
DC/DC CHARG
T62.101.C.00 V.P2
19.21030.391 1
Modem board
(CIS)
MODEM MODULE
AC-5614BMCB
54.09041.051 1
Modem board
(Ambit)
MODEM 1641B
AMBIT/
T62.103.C.00
54.09042.001 1
Audio I/O and
battery
connection
board
500 AUDIO
BOARD 4L
55.45B04.001 5
CD-ROM
control panel
board
500 CD-ROM
CONTROL
BOARD
55.45B05.001 5
CPU
CPU-233
ACER
500 CPU BOARD
T-233
55.45B02.041 1
CPU-233
Hitachi
VEGA CPU
BOARD T-233
55.45B02.021 1
CPU-266
ACER
500 CPU BOARD
T-266
55.45B02.031 1
CPU EMI
shield
ASSY CPU EMI
BRKT AN500
60.45B13.001 50
CPU heat sink ASSY CPU HSINK
AN500
60.45B10.001 5
HDD
Spare Parts List (P/N:91.45BXX.XXX)
Part Name Description
Part No.
*
Q'ty
†
