Acer Extensa 5630 - LCD Module Disassembly Process

Chapter 3 93
LCD Module Disassembly Process
LCD Module Disassembly Flowchart
Screw List
Item Screw Color Part No.
B M2 x L4 Silver 86.9A552.4R0
C M2.5 x L5 Black 86.00E33.736
G M2.5 x L5 Black 86.00F87.735
LCD MODULE
LCD BEZEL
Cx4
LCD ASSEMBLY
LEFT LCD
BRACKET
Bx2
RIGHT LCD
BRACKET
Bx2
LCD FPC
CABLE
LCD BACK PANEL
ANTENNAS
LCD MODULE DISASSEMBLY
Gx6, B2
VGA
CAMERA
