Acer Extensa 5630 - Left View; Right View

Chapter 1 7
Left View
Right View
# Icon Item Description
1 Kensington lock slot Connects to a Kensington-compatible computer security
lock.
2 Acer EasyPort IV
connector
Connects to Acer EasyPort IV
(only for certain models).
3 External display
(VGA) port
Connects to a display device (e.g., external monitor, LCD
projector).
4 Ethernet (RJ-45)
port
Connects to an Ethernet 10/100/1000-based network.
5 HDMI port Supports high definition digital video connections (only
for certain models).
6 Two USB 2.0 ports Connect to USB 2.0 devices (e.g., USB mouse, USB
camera).
7 PC Card slot Accepts one Type II PC Card.
8 ExpressCard/54
slot
Accepts one ExpressCard/54 module.
9 PC Card slot eject
button
Ejects the PC Card from the slot.
Icon Item Description
1 Optical drive Internal optical drive; accepts CDs or DVDs.
2 Optical disk access
indicator
Lights up when the optical drive is active.
3 Optical drive eject
button
Ejects the optical disk from the drive.
