Chapter 3 71
Removing the Keyboard
1. See “Removing the Battery Pack” on page 56.
2. See “Removing the Middle Cover” on page 68.
3. Remove the two screws (A) securing the keyboard.
4. Carefully pry loose the keyboard and turn it over on the touchpad area.
Step Size (Quantity) Color Torque
1~2 M2 x L3 (2) Silver 1.6 kgf-cm
To Next Page
