70 Chapter 3
3. Remove the one screw (A) securing the power board to the middle cover.
4. Release the power board from the latches and remove it from the middle cover.
Step Size (Quantity) Color Torque
1 M2 x L3 (1) Silver 1.6 kgf-cm
