10 Chapter 1
Bottom View
Icon Item Description
1 Hard disk bay Houses the computer's hard disk (secured with
screws).
2 Acer DASP (Disk
Anti-Shock
Protection)
Protects the hard disk drive from shocks and
bumps (only for certain models).
3 Ventilation slots Enable the computer to stay cool, even after
prolonged use.
4 Memory
compartment
Houses the computer's main memory.
5 Battery lock Locks the battery in position.
6 Battery release
latch
Releases the battery for removal.
7 Battery bay Houses the computer's battery pack.
