Chapter 1 33
Audio Interface
Item Specification
Audio Controller Realtek ALC883 Azalia and Amplifier Maxim MAX9710 &
MAX4411
Audio onboard or optional Built-in
Mono or Stereo Stereo
Resolution 18 bit stereo full duplex
Compatibility HD audio Interface; S/PDIF output for PCM or AC-3
content
Sampling rate 1Hz resolution VSR (Variable Sampling Rate)
Internal microphone Yes
Internal speaker / Quantity Yes/2 (1.5W speakers)
Video Memory
Item Specification
Chipset VGA CARD NB9P-GS/Intel GMA970 VGA
Memory size 512M GDDR3/
Item Specification
Chipset ICH8M
USB Compliancy Level 2.0
OHCI USB 1.1 and USB 2.0 Host controller
Number of USB port 3
Location Two on the right side/one on the front
Serial port function control Enable/Disable by BIOS Setup
System Board Major Chips
Item Controller
Core logic Mobile Intel® GM945/PM945 + ICH8M Express Chipset
VGA nVidia GeForce 9300 GS/ATI Mobility HD 3470/UMA
USB 2.0 Intel ICH8M
Super I/O controller N/A
MODEM ALC 883
Bluetooth FOXCONN BCM2045 V2
Wireless 802.11 b+g WLAN 802.11ABGN SHIRLEYPEAK1*2
PCMCIA/ 5 in 1 Card Reader JMicron Cardreader JMB385
Audio Codec Audio Azalia(ALC888S)
Keyboard
Item Specification
Keyboard controller NS PC97541V
