86 Chapter 3
19. Remove the three screws (2 x F, 1 x A) securing the bracket to the upper case.
20. Remove the touchpad bracket.
Step Size (Quantity) Color Torque
1~2 M2 x L3 (2) Silver 1.6 kgf-cm
3 M2 x L3 (2) Silver 1.6 kgf-cm
