Acer P1165E - Lamp Module Disassembly

P1165E&P5260E 18
3.3 Disassembly Lamp Module
Step Figure Description
1
z Turn off the projector.
z Unplug the power cord.
z Open the lamp cover as the photo
showing (Push the switch on
“OPEN” to unlock the lamp
cover, then push the lamp cover
as the direction the arrow
showing. Uncover the lamp cover
then you open the cover.)
2
z Loosen the two screws of lamp
module
S6
