3. Exploded Diagram
3.2-2 Packing Exploded Diagram ( A+D monitor)：
ITEM QT'Y PART DESCRIPTION REMARK
1 1 CARTON
1925-1001-1070 EPS-TOP
2 1
1925-1001-1080 EPS-BOTTOM
3 1 1925-1100-4120 EPE.BAG
4 TAP
5 1 USER'S MANUAL & GUARANTEE CARD
6 1 3522-0042-0300 LCD MONITOR
7 1 1801-0540-5010 NECK
8 1 1801-0540-4010 BASE
9 1 POWER CABLE
10 1 SIGNAL CABLE
11 1 ADAPTER CABLE
12 1 DVI CABLE
