1. Product Specification
ACER S2 30 HL
5
E. Flat Panel Connector
a. Input signal connector of mini-LVDS
Pin Signal Descript ion Pin Signal Descript ion
1 GND Ground 26 VCOMC VCOMC Voltage
2 LV5- Mini LVDS Receiver Signal(5-) 27 VCOMC VCOMC Voltage
3 LV5+ Mini LVDS Receiver Signal(5+) 28 VCOMD VCOMC Voltage
4 LV4- Mini LVDS Receiver Signal(4-) 29 VCOMD VCOMC Voltage
5 LV4+ Mini LVDS Receiver Signal(4+) 30 VCC Logic Voltage
6 LV3- Mini LVDS Receiver Signal(3-) 31 VCC Logic Voltage
7 LV3+ Mini LVDS Receiver Signal(3+) 32 VDD Panel Driving Voltage
8 GND Ground 33 VDD Panel Driving Voltage
9 LVCLK- Mini LVDS Receiver Clock Signal- 34 VDD Panel Driving Voltage
10 LVCLK+ Mini LVDS Receiver Clock Signal+ 35 VGH Gate High Voltage
11 GND Ground 36 VGH Gate High Voltage
12 LC2- Mini LVDS Receiver Signal(2-) 37 VGL VGL voltage
13 LV2 Mini LVDS Receiver Signal(2+) 38 VGL VGL voltage
14 LV1- Mini LVDS Receiver Signal(1-) 39 G_RES GIP Reset Pulse
15 LV1+ Mini LVDS Receiver Signal(1+) 40 GVDD_E GIP Panel VDD for Even Gate TFT
16 LV0- Mini LVDS Receiver Signal(0-) 41 GVDD_O GIP Panel VDD for Odd Gate TFT
17 LV0+ Mini LVDS Receiver Signal(0+) 42 CLK4 GIP GATE Clock4
18 GND Ground 43 CLK4 GIP GATE Clock4
19 SOE Source Output Enable SIGNAL 44 CLK3 GIP GATE Clock3
20 POL2 Polarity Control Signal 45 CLK3 GIP GATE Clock3
21 POL Polarity Control Signal 46 CLK2 GIP GATE Clock2
22 CSC Charge Share mode control Signal 47 CLK2 GIP GATE Clock2
23 H2DOT Horizontal 2 Inversion Sognal 48 CLK1 GIP GATE Clock1
24 ICLK_REST Vertical Start Plus 49 CLK1 GIP GATE Clock1
25 GND Ground 50 GND Ground
b. Input signal connector of LED Backlight power
Pin Signal Descript ion Pin Signal Descript ion
1 FB1 Channel1 current Feed Back 6 Vled LED Power supply (common Input)
2 NC No connection 7 NC No connection
3 NC No connection 8 NC No connection
4 NC No connection 9 NC No connection
5 Vled LED Power supply (common Input) 10 FB2 Channel2 current Feed Back
1.3.2 Input Signals:
Video Input Signals Range(Analog RGB Signal)
No. Sym bol Item M in Max Unit Remark
1 Fh Ho rizontal Frequency 30 83 kHz Min imum range
2 Fv Vertical Frequency 50 75 Hz Min imum range
3 Fclk Pixel Clock Freque ncy 173 MHz
4 Vih Hi Le vel I nput 2 5 V No te 1)
5 Vil Low Level In put 0 0.8 V No te 1)
6 Vid eo RGB Analo g Video Level 0 0.735 V
75
Ω
to Ground
Note 1) 2.2k Ω to Ground. Schmitt-Triggers Input. Support 3.3V H & V SYNC Output device.
1.3.2.1 Video Signal Amplitudes:
The video inputs consist of Red, Green and Blue signals each has its own coaxial cable terminated at the
monitor. These video signals are analog levels, where 0V corresponds to black, and 735mV is the
maximum signal amplitude for the respective color. The video signal is terminated with 75 ohms.
