9
English
Getting Started
Connecting the Projector
Note: To ensure the projector works well with your computer,
# Description # Description
1 Power cord 7 3 RCA component cable
2 Audio cable 8 Composite video cable
3 HDMI (MHL) cable 9 RS232 cable
4 VGA to component video/HDTV adapter 10 WirelessHD dongle
5 VGA cable 11 Wireless dongle
6 USB cable
HDTV adapter
RCA
R
L
11
1
43 3
3
5 5 6
9
7
8
2
2
10
2
DVD player, Set-top
box, HDTV receiver
VGA/HDMI
RS232
Video Output
Display
Speakers
Smartphone/
tablet
