ACORN 80 Installation Manual
APPENDIX 10
Rationalisation Procedures
2 The base of the seat should now look like this.
3 Position the swivel pin in the opposite side of the
base casting and secure in with the pre-assembled
PATCHED grub screw using, ensuring there is no
movement in the pin.
4 The lift has now been changed to a Left Handed seat.
5 Place seat on carriage and check to see if the swivel
release operates freely and locks correctly.
IF PATCHED BOLT IS NOT PRESENT, USE
LOCTITE 243 AND SECURE IN POSITION
