System Memory ( DIMM Module)
This 6BX86/6VIA86/6VIA86P mainboard supports, three 168 pins
DIMM ( Dual Inline Memory Module) (6ZX86 supports two DIMMs)
of 16 MB, 32 MB, 64 MB, 128 MB ,256MB to form a memory size
between 16MB to 256MB.
The DRAM can be either 45ns,50ns,or 60ns 3.3v SDRAM,and 3.3v
Enhanced Data Output (EDO) RAM.
Install memory in any or all Banks in Combination:
Bank Memory module
DIMM 1 16MB,32MB,64MB,128MB,256MB
( Bank 0-1 ) 168 pin,3.3v SDRAM / EDO RAM
DIMM 2 16MB,32MB,64MB,128MB,256MB
( Bank 2-3 ) 168 pin 3.3v,SDRAM / EDO RAM
DIMM 3 16MB,32MB,64MB,128MB,256MB
( Bank 4-5 ) 168 pin 3.3v,SDRAM / EDO RAM
Total System Memory(Max 768MB)
Note :


 The DIMM Slot does not support any 5v EDO DIMM
module.


 The DIMM Slot does not support any 5v SDRAM
DIMM module.


 Memory speed setup is required through "Auto Con-
figuration" in BIOS chipset Setup of BIOS SOFTWARE.
If several speed memorious are used, You must set Auto
Configuration to low. Example If both 50ns, 60ns are
used, Please set Auto configuration to 60ns.


 It's allowed any DIMM module put in any DIMM slot.
It's allowed there are different capacity DIMM module
in all DIMM slot.
