11 Technical specifications of the medical device
11.1 Identification
Manufacturer SATELEC, a company of Acteon group
Name of the medical device Newtron
®
P5 B.LED
11.2 Generator
Supply voltage 100 - 240 VAC
Power supply frequency 50 - 60 Hz
Power consumption 60 - 60VA
Voltage supplied to handpiece 150VAC
Output frequency Minimum 28kHz
Power setting range 1 - 20
Type of leakage currents B
Operating mode Intermittent: 10 minutes ON / 5 minutes OFF
Electrical rating I
Internal fuse not accessible to the user Ref : FU1 / T1,5AL 125V - SMD - Interrupting capacity: 50A
Fuse (mains connector) 2 fuses T 1AL 250V – 5mm x 20mm - Interrupting capacity: 35A
Width 156mm
Height 102mm
Depth 185mm
Weight 1 430g with pedal, water pipe and handpiece cord
Ingress protection rating IPX0
11.3 Length of cords
Handpiece cord 2 500 mm +/- 50 mm
Control pedal cord 2 500 mm +/- 50 mm
11.4 Irrigation
Water pressure at inlet from 1 to 5 bars (15 to 73 p.s.i.)
Maximum water output flow at the end of the
handpiece
100 ml/min at 5 input bar
11.5 Footswitch
Width 72mm
Height 30mm
Depth 105mm
Weight 220g
Ingress protection rating IPX1
11.6 Environmental characteristics
Ambient operating temperature 10 to +30°C
Operating RH 30% to 75%
User Manual | Newtron
®
P5 | J61101 | V6 | (13)|09/2017 | NBACEN030F - Page 27/38
