ACTi B41 - Page 34

www.acti.com
Hardware Manual
34
5. Insert the sealing insert and attach it at the end of the flex conduit.
6. Pull the device cables through the gland body.
7. Attach the terminal blocks, see Other Connections on page 36 for more information.
8. Connect the cables to the corresponding connectors on the camera.
