HARDWARE MANUAL
13
Mounting Solutions
There are several mounting options that you can use to install the camera. Select the most
suitable solution for your installation environment.
Mount Types
Accessories
Surface Mount
Suitable when mounting the camera on flat and smooth surface, like ceilings
or walls. This solution directly installs the camera to the surface without
additional accessories. See Installing the Camera on a Surface on page
14 for more information.
Tilted Wall
Mount
Suitable when mounting the camera on high walls. The camera can be tilted
10° to capture a larger viewing angle below the camera and less on the
ceiling.
Pendant Mount
Suitable when mounting the camera on hard and high cielings.
Horizontal Pole
Mount
Suitable when mounting the camera on a horizontal pole.
Vertical Pole
Mount
Suitable when mounting the camera on a vertical pole.
Corner Mount
Suitable when mounting the camera on a corner area. The camera can also
be tilted 10° to capture a larger viewing angle below the camera and less
above.
NOTE:
 For more information about the mounting solutions and accessories, please check the
online Mounting Accessory Selector (http://www.acti.com/mountingselector).
 The mounting accessories are not included in the package. Contact your sales agents
to purchase.
