Step 3: Prepare to Waterproof and Connect the Cable
The camera comes with two (2) glands used for waterproof installation:
 Cable Gland: For use with an Exterior-grade Ethernet cable. Exterior-grade
Ethernet cables are already waterproof. See Waterproof Solution with Naked Cable
on page 19.
 Conduit Gland: For use with a flexible conduit. This solution is recommended when
an exterior-grade Ethernet cable is not available or other cables, such as power
adapter, DI/DO devices, etc. will be connected with the camera. See Waterproof
Solution with Conduit on page 21.
Determine the type of waterproof solution that is applicable to your installation requirements
and prepare the necessary accessories or purchase extra materials.
Cable Gland
Conduit Gland
For use with an Exterior-grade Ethernet
cable (not included in the package).
For use with 1/2” flexible conduit (not
included in the package)
