HARDWARE MANUAL
16
Step 2: Open the Camera Cover
NOTE: To avoid scratches or leaving fingerprints on the dome cover, it is recommended to
retain the plastic covering the dome cover until the camera is completely installed. However,
the plastic has been removed on some of the pictures in this documentation to show clarity of
the procedures being described.
1. If the cables will pass through the surface, remove the cap covering the bottom hole of
the camera, and attach the cap to the side hole to close it. The network cable will pass
through the surface and the bottom hole to the camera.
2. With the bundled hex screwdriver, loosen the three (3) screws securing the dome cover.
3. Carefully lift to open the cover and place it on the side of the camera.
NOTE: Do not abruptly lift the cover; a cable is connected on the camera body and the cover.
