Mounting Solutions
There are several mounting solutions that you can use to install the camera. Select the most
suitable solution for your installation environment.
Mount Types
Accessories
Surface Mount
Suitable when mounting the camera directly to walls or ceilings. See
Installing the Camera on a Surface on page 13 for mounting instructions.
Flush Mount
Suitable when mounting the camera discretely above dropped ceilings
wherein only the dome cover will be visible underneath the ceiling.
PMAX-1006
Gang Box
Suitable when mounting the camera in specific regions where the use of
gang box is required by law.
PMAX-0803
Pendant Mount
Suitable when mounting the camera on hard and high ceilings.
PMAX-0101 PMAX-0103 (Straight Tube with Bracket)
PMAX-0101 PMAX-0102 (Straight Tube)
