Step 2: Prepare the Accessories
1. Prepare the Conduit Gland accessories (included in the waterproof cable kit) and flexible
conduit cable (not included), with ½” trade size.
2. Detach the parts of the main body, as follows:
NOTE: The Lock Nut is designed for use with junction boxes and will not be used in this
installation. Please set it aside.
Clamping Nut
Sealing Insert
Body
Lock Nut
2-Sided Female
Type Connector
Converter
Washer
Main Body
Trade size 1/2"
