ACTi E616 - How to Adjust the Viewing Angle and Flocus; E610

www.acti.com
Hardware Manual
26
How to Adjust the Viewing Angle and Flocus
E610
Camera Parts Overview
Adjustment Procedures
1. Loosen the tilt adjustment screws, adjust the tilt, and then tighten back the screws to fix
the tilt position.
2. Loosen the rotation adjustment screw, rotate the viewing orientation, and then tighten
back the screw to fix the orientation.
1
2
3
