Installation Procedures
There are several mounting options that you can use to install the camera. Select the most
suitable solution for your installation environment.
Mounting Solutions
Mount Types
Accessories
Surface Mount
Suitable when mounting the camera on hard or dropped ceilings. The
surface mount comes bundled with the camera package. See Using the
Bundled Surface Mount on page 21 for mounting instructions.
Flush Mount
Suitable when mounting the camera discretely above dropped ceilings
wherein only the dome cover will be visible underneath the ceiling. See
Using the Flush Mount on page 24 for mounting instructions.
PMAX-1010
Pendant Mount
Suitable when mounting the camera on hard and high ceilings.
PMAX-0110 PMAX-0103 (Straight Tube with Bracket)
PMAX-0110 PMAX-0102 (Straight Tube)
Straight Wall
Mount
Suitable when mounting the camera on straight walls.
PMAX-0311 (L-Type Wall Mount)
