AVAILABLE KITS AND ACCESSORIES
COMFORT E TANK USED AS ELECTRIC DHW TANK ONLY
Do not power the heating element if the oustide tank is not filled and bled.
1. System lling valve
2. Safety valve calibrated to 3 bar
3. Expansion vessel
4. Isolation valve, heating system
5. Pressure gauge
A
B
E
S
DC
TCTH
DHW connection kit available
(code:10800102)
A. DHW temperature control valve
B. Mixed domestic hot water outlet
C. Cold water supply
D. Drainage connection
E. DHW expansion vessel connection
S. Safety valve (7 bar)
TH. Tank hot water outlet
TC. Tank cold water inlet
This connection to
be plugged.
5
4
1
2
3
