USER'S GUIDE
CONTROL PANEL
Key :
1. Control thermostat [60/80°C] - To set the domestic hot water (DHW) temperature.
2. Fuse FF 12,5 Amp - To provide an electric protection to the appliance.
3. Summer / Winter switch - To activate the heating pump of the installation/deactivate the
electrical heating element (
- winter position) or activate the electrical heating element/
deactivate the installation pump ( - summer position).
4. Heating-element-on indicator - The built-in indicator lights when the heating element is
activated (
position of the summer / winter switch).
USER'S GUIDE
CONTROL PANEL
Heating
element ON
Heating
element OFF
1
2 3
4
