TECHNICAL CHARACTERISTICS
DIMENSIONS AND MAIN CHARACTERISTICS
Tank dimensions
Comfort E
100 130 160 210 240
A mm 845 1005 1205 1480 1725
B mm 365 525 725 1000 1245
C mm 630 790 990 1260 1510
Empty weight Kg 37 40 47 58 65
Main characteristics
Comfort E
100 130 160 210 240
Total capacity L 105 130 161 203 242
Primary capacity L 30 55 62 77 78
DHW capacity L 75 75 99 126 164
Primary connection [F] " 1 1 1 1 1
DHW connection [M] " 3/4 3/4 3/4 3/4 3/4
Primary pressure drop* mbar 19.6 22.4 23.5 40.6 46.5
Heating surface area m² 1.03 1.03 1.26 1.54 1.94
Max Design Pressure* bar 10 10 10 10 10
Reheat Performance - Primary Hea-
ting Power Input*
kW 18.4 18.4 24.7 32.2 39.2
Primary ow rate (to achieve Reheat
Performance) *
L/sec. 0.7 0.7 0.7 1.25 1.25
Reheat time* min 10 10 10 9 9
Standing Heat Loss*
kWh/24h 1.39 1.54 1.7 1.85 1.94
W 58 64 71 77 81
* According to EN12897:2006
