1 – Signal Lamp, the Scanning Process Start;
2 – Signal lamp, Readiness of the System for Operation
Figure 3.4 – Signal Lamp Assemblies
The System external covers are equipped with a panel to control cables and power sup-
ply cables output.
3.4 X-RAY TUBE MODULE
The X-ray tube module includes:
- Rotary frame;
- X-ray generator;
- Beam-limiting unit;
- X-ray Detector;
- Electrics;
- Rotary mechanism.
The X-ray tube module is shown in Figure 3.5.
OPERATION OF THE SYSTEM WITH THE EXTERNAL CO-
VERS REMOVED IS FORBIDDEN.
