Appendix F: Controller LED and I2C Connector Quick Reference ● 128
● I2C Mating Cable Connector: Molex 22-43-3030 or equivalent
J5:
● Adaptec RAID 5805/5805Q Status LED Board Connector: Molex 10-89-7162 or
equivalent
● Status LED Mating Cable Connector: Molex 22-55-2161 or equivalent
J14 (Adaptec RAID 5805/5805Q only):
Adaptec RAID 51245 LED and I2C Connector Specification
● Adaptec RAID 51245 Activity LED Header Connector for CN0/CN1: Molex 10-89-7162
or equivalent
● Activity LED Header Mating Cable Connector: Molex 22-55-2161 or equivalent
J5 Pin Number Signal
3I2C Clock
2Ground
1I2C Data
J14 Pin Number Signal Description
22-55-2161
Pin Number
1 +3.3V LED Anode 2
2 STATUS CN0, LANE 0LED Cathode 1
3 +3.3V LED Anode 4
4 STATUS CN0, LANE 1LED Cathode 3
5 +3.3V LED Anode 6
6 STATUS CN0, LANE 2LED Cathode 5
7 +3.3V LED Anode 8
8 STATUS CN0, LANE 3LED Cathode 7
9 +3.3V LED Anode 10
10 STATUS CN1, LANE 0 LED Cathode 9
11 +3.3V LED Anode 12
12 STATUS CN1, LANE 1LED Cathode 11
13 +3.3V LED Anode 14
14 STATUS CN1, LANE 2LED Cathode 13
15 +3.3V LED Anode 16
16 STATUS CN1, LANE 3LED Cathode 15
2258400-R ASR-51245 RoHS Kit
2258300-R ASR-51245 RoHS Single
