Appendix F: Controller LED and I2C Connector Quick Reference ● 147
Adaptec RAID 2045 LED Connector Specification
● Adaptec RAID 2045 Aggregate Activity LED Board Connector: Molex 22-28-4023 or
equivalent
● Aggregate LED Mating Cable Connector: Molex 50-57-9002 or equivalent
J1:
Adaptec RAID 2405/2405Q LED and I2C Connector
Specification
● Adaptec RAID 2405/2405Q Activity LED Header Connector: Molex 10-89-7082 or
equivalent
● Activity LED Header Mating Cable Connector: Molex 22-55-2081 or equivalent
J2:
● Adaptec RAID 2405/2405Q Aggregate Activity LED Board Connector: Molex 22-28-4023
or equivalent
● Aggregate LED Mating Cable Connector: Molex 50-57-9002 or equivalent
2260300-R ASR-2045 RoHS SGL
J1 Pin Number Signal Description
2 ACTIVITY LED Cathode
1 +3.3V LED Anode
2260100-R ASR-2405 RoHS KIT
2260200-R ASR-2405 RoHS SGL
2268300-R ASR-2405Q RoHS Single
J2 Pin Number Signal Description
22-55-2161
Pin Number
1 +3.3V LED Anode 2
2 ACTIVITY CN0, LANE 0 LED Cathode 1
3 +3.3V LED Anode 4
4 ACTIVITY CN0, LANE 1 LED Cathode 3
5 +3.3V LED Anode 6
6 ACTIVITY CN0, LANE 2 LED Cathode 5
7 +3.3V LED Anode 8
8 ACTIVITY CN0, LANE 3 LED Cathode 7
