Appendix F: Controller LED and I2C Connector Quick Reference ● 135
Adaptec RAID 3085 LED Connector Specification
● Adaptec RAID 3085 LED Board Connector: Molex 10-89-7162 2.54mm 2x8 Header or
equivalent
● LED Mating Cable Connector: Molex 22-55-2161 or equivalent
J10:
Adaptec RAID 3405 LED and I2C Connector Specification
● Adaptec RAID 3405 LED Board Connector: Molex 10-89-7162 2.54mm 2x8 Header or
equivalent.
● LED Mating Cable Connector: Molex 22-55-2081 or equivalent.
2251600-R ASR-3085 RoHS Kit
2251600JA-R ASR-3085/JA RoHS Kit
2252200-R ASR-3085 RoHS Single
2252300-R ASR-3085/256MB RoHS Single
J10 Pin Number Signal Description
22-55-2161
Pin Number
1 +3.3V CONNECTOR J3-PORT0 Anode 2
2 ACT0_7_LED_L (0) CONNECTOR J3-PORT0 Cathode 1
3 +3.3V CONNECTOR J3-PORT1 Anode 4
4 ACT0_7_LED_L (1) CONNECTOR J3-PORT1 Cathode 3
5 +3.3V CONNECTOR J3-PORT2 Anode 6
6 ACT0_7_LED_L (2) CONNECTOR J3-PORT2 Cathode 5
7 +3.3V CONNECTOR J3-PORT3 Anode 8
8 ACT0_7_LED_L (3) CONNECTOR J3-PORT3 Cathode 7
9 +3.3V CONNECTOR J5-PORT0 Anode 10
10 ACT0_7_LED_L (4) CONNECTOR J5-PORT0 Cathode 9
11 +3.3V CONNECTOR J5-PORT1 Anode 12
12 ACT0_7_LED_L (5) CONNECTOR J5-PORT1 Cathode 11
13 +3.3V CONNECTOR J5-PORT2 Anode 14
14 ACT0_7_LED_L (6) CONNECTOR J5-PORT2 Cathode 13
15 +3.3V CONNECTOR J5-PORT3 Anode 16
16 ACT0_7_LED_L (7) CONNECTOR J5-PORT3 Cathode 15
2251800-R ASR-3405 RoHS KIT
2251800JA-R ASR-3405/JA RoHS KIT
2251900-R
ASR-3405 RoHS Single
