Appendix F: Controller LED and I2C Connector Quick Reference ● 140
● Adaptec RAID 31205 LED Board Connector: Molex 10-89-7162 2.54mm 2x8 Header or
equivalent
● LED Mating Cable Connector: Molex 22-55-2081 or equivalent
J17:
● Adaptec RAID 31205 Aggregate Activity LED Board Connector: Molex 22-28-8022
2.54mm 1x2 RA Header or equivalent
● LED Mating Cable Connector: Molex 50-57-9002 or equivalent
J11:
● Adaptec RAID 31205 Aggregate Activity LED Board Connector: Molex 22-28-8022
2.54mm 1x2 RA Header or equivalent
● LED Mating Cable Connector: Molex 50-57-9002 or equivalent
J12:
● Adaptec RAID 31205 Aggregate Activity LED Board Connector: Molex 22-28-8022
2.54mm 1x2 RA Header or equivalent
● LED Mating Cable Connector: Molex 50-57-9002 or equivalent
15 +3.3V CONNECTOR J5-PORT3 Anode 16
16 ACT0_7_LED_L (7) CONNECTOR J5-PORT3 Cathode 15
Pin Number Signal Description
22-55-2081
Pin Number
1 +3.3V CONNECTOR J18-PORT0 Anode 2
2 ACT8_15_LED_L (0) CONNECTOR J18-PORT0 Cathode 1
3 +3.3V CONNECTOR J18-PORT1 Anode 4
4 ACT8_15_LED_L (1) CONNECTOR J18-PORT1 Cathode 3
5 +3.3V CONNECTOR J18-PORT2 Anode 6
6 ACT8_15_LED_L (2) CONNECTOR J18-PORT2 Cathode 5
7 +3.3V CONNECTOR J18-PORT3 Anode 8
8 ACT8_15_LED_L (3) CONNECTOR J18-PORT3 Cathode 7
Pin Number Signal Description
2 AGGREGATE0_3_L Aggregate Cathode – Connector J3 Ports 0-3
1 +3.3V Aggregate Anode
Pin Number Signal Description
2 AGGREGATE4_7_L Aggregate Cathode – Connector J5 Ports 0-3
1 +3.3V Aggregate Anode
J10 Pin Number Signal Description 22-55-2161
