Appendix F: Controller LED and I2C Connector Quick Reference ● 144
● Adaptec RAID 31605 Aggregate Activity LED Board Connector: Molex 22-28-8022
2.54mm 1x2 RA Header or equivalent
● LED Mating Cable Connector: Molex 50-57-9002 or equivalent
J11:
● Adaptec RAID 31605 Aggregate Activity LED Board Connector: Molex 22-28-8022
2.54mm 1x2 RA Header or equivalent
● LED Mating Cable Connector: Molex 50-57-9002 or equivalent
J12:
● Adaptec RAID 31605 Aggregate Activity LED Board Connector: Molex 22-28-8022
2.54mm 1x2 RA Header or equivalent
● LED Mating Cable Connector: Molex 50-57-9002 or equivalent
J15:
● Adaptec RAID 31605 Aggregate Activity LED Board Connector: Molex 22-28-8022
2.54mm 1x2 RA Header or equivalent
● LED Mating Cable Connector: Molex 50-57-9002 or equivalent
J16:
● Adaptec RAID 31605 I2C Board Connector: Molex 22-43-6030 or equivalent
● I2C Mating Cable Connector: Molex 22-43-3030 or equivalent
Pin Number Signal Description
2 AGGREGATE0_3_L Aggregate Cathode – Connector J3 Ports 0-3
1 +3.3V Aggregate Anode
Pin Number Signal Description
2 AGGREGATE4_7_L Aggregate Cathode – Connector J5 Ports 0-3
1 +3.3V Aggregate Anode
Pin Number Signal Description
2 AGGREGATE8_11_L Aggregate Cathode – Connector J18 Ports 0-3
1 +3.3V Aggregate Anode
Pin Number Signal Description
2 AGGREGATE12_15_L Aggregate Cathode – Connector J14 Ports 0-3
1 +3.3V Aggregate Anode
