PR Series Installation, Operation, and Maintenance Manual
2.3 - Unit Nomenclature Example, Cont.
Digit: Description: Feature:
25 Electric Heating Capacity
0 = None
A = 5kW 240/480/575V - 3.75kW 208V
B = 10kW 240/480/575V - 7.5kW 208V
C = 15kW 240/480/575V - 11.25kW 208V
D = 20kW 240/480/575V - 15kW 208V
E = 25kW 240/480/575V - 18.75kW 208V
F = 30kW 240/480/575V - 22.5kW 208V
G = 35kW 240/480/575V - 26.25kW 208V
H = 40kW 240/480/575V - 30kW 208V
K = 50kW 240/480/575V - 37.5kW 208V
M = 60kW 240/480/575V - 45kW 208V
N = 70kW 240/480/575V - 52.5kW 208V
P = 80kW 240/480/575V - 60kW 208V
R = 100kW 240/480/575V - 75kW 208V
S = 110kW 240/480/575V - 81.4kW 208V
T = 120kW 240/480/575V - 90kW 208V
U = 130kW 240/480/575V - 97.5kW 208V
V = 140kW 240/480/575V - 105kW 208V
W = 150kW 240/480/575V - 112.5kW 208V
26 - 27 Gas Heating Capacity
00 = None
A1 = 75MBH
B1 = 100MBH
C1 = 150MBH
D1 = 200MBH
E1 = 250MBH
F1 = 300MBH
G1 = 350MBH
H1 = 400MBH
J1 = 500MBH
K1 = 600MBH
A2 = 100+100MBH
G2 = 150+150MBH
B2 = 200+200MBH
C2 = 250+250MBH
D2 = 300+300MBH
F2 = 350+350MBH
E2 = 400+400MBH
H2 = 500+500MBH
J2 = 600+600MBH
A4 = (4) 200MBH
B4 = (4) 250MBH
C4 = (4) 300MBH
D4 = (4) 350MBH
E4 = (4) 400MBH
