18
First install the rocker arm on the A18 into the servo. When installing, the mounting hole of
the rocker arm should be aligned with the round hole on the A18. Install it at the angle
shown below.
Effect diagram after assembling
5. Then fix the other end of the A18 to the servo on the A20.
Assemble the following components
M2.5*8 Screw x1
A18 x1
