31
6. Fix N20 Motor Seat on A11.
Fix the other N20 Motor Seat on A11.
Assemble the following components
A11 x1
M2*10 Screw x2
Here the side with URL
faces up
M2 Nut x2
Effect diagram after assembling
Effect diagram after assembling
