11. Fix 3 Tracking Module on A01.
12. Fix Raspberry Pi Camera on A12.
Assemble the following components
At this point, the 3 Tracking Module has been plugged
into the wiring. For the convenience to read, only one
end of the wiring is shown here. Same as bellow.
Effect diagram after assembling
Effect diagram after assembling
(When the screw is obstructed or cannot
be screwed in, turn over the plate and
screw in the other side.)
Assemble the following components
M1.4*6 Self-tapping
Screw x4
To Next Page
