5
SPECIFICATIONS
1) DIMENSIONS/CONNECTIONS
2) Rating
MODEL HZB-30F
POWER SUPPLY VOLTAGE 1Phase, 220-240/50Hz
CLAIMATE CLASS SN/N/ST/T
ELECTRICAL PROTECTIO N CLASS I
ICE MAKING RATING (Amps) 1.3Amp
ICE HARVEST RATING (Amps) 1.8 Amp
ICE MAKING CAPACITY (KG/24H) 30 kg/24Hour
*
REFRIGERANT CHARGE R290, 52g
VESICANT
C
5
H
10
UNIT DIMENSIONS(W X D X H) (mm) 345x339x602
NET W EIGHT(KG ) 15.8Kg
CONNECTION POWER CORD---- 0.75 mm
2
WATER SUPP LY----6.35mm diameter
DRAIN PIPE---
-Φ16mm SYLPHON BELLOWSS
MAX ICE STORAGE CAPACITY(KG) 4 Kg
ACCESSORIES ICE SCOOP, INSTALLATION KITS
RUNNING CONDITION S
ROOM TEMP 10-43℃
WATER SUPPLY T EMP 5-35℃
WATER SUPPLY PRESSUR E 0.04-0.6 MPa
NOTE *: TESTED AT 21 ℃ ROOM TEMPERATURE AND 10℃ WATER TEMPERATURE.
