Adkins INLINE 800 - Description of Parts; Internal Components

page 6
2.
DESCRIPTION OF PARTS
1. Main trip switch/breaker
2. AC contactor
3. 24V power box
4. Electromagnetic relay
5. 2-channels driver board
6. Main control board
7. 5-channels driver board
8. Isolation transformer
9. Paper feed gear set
10. Powder removing brushless motor
11. witchOn/Off s
12. Powder shake gear set
13. Touch screen
14. Emergency stop switch
Disconnect the mains power supply to the equipment
before carrying out any maintenance/repair work.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
