CF1 CF2 SPEED
OFF OFF SPEED - 1
ON OFF SPEED - 2
OFF ON SPEED - 3
ON ON SPEED - 4
12
Symbol
Control circuit terminal
Terminal Description
GND Analog common terminal Common terminal of free analog terminals
10V Analog source Power source +10V of analog terminals
FA1 Free analog terminal 1 See functions description (CD44)
FA2 Free analog terminal 2 See functions description (CD45)
MET Frequency meter terminal
0~100% duty open collector output or
0~10VDC / 2mAoutput (0~CD14)
MA
Relay output RUN
Relay output contact (normal open)
MB Relay output contact (normal close)
MC Relay output contact (common)
A Alarm output A Fault alarm contact (normal open)
B Alarm output B Fault alarm contact (normal close)
C Alarm output C Fault alarm contact (common)
24V Source terminal Source terminal of control board
FWD Forward operation Forward operation / stop terminal
REV Reverse operation Reverse operation / stop terminal
CF1
Multistage speed terminal
CF2
FT1 Multi function terminal 1 See functions description (CD42)
FT2 Multi function terminal 2 See functions description (CD43)
RST Reset Reset
ARR
Operation output terminal
Frequency arrival signal
Photocoupler output 48VDC/50mA(MAX)
COM Common terminal Common terminal of control board
