7-6 Main circuit terminals
Wire Wire type Torque
AP2G3-337~375
AP4G3-337~3110
Input (R/L1,S/L2,T/L3)
Output(U,V,W,P,PR)
10AWG
(5.5mm
2
)
Stranded copper only
(600V/80 )℃
18Kg-cm
(15.6lb-in)
AP2G3-3110~3220
AP4G3-3150~3220
Input (R/L1,S/L2,T/L3)
Output(U,V,W,P,PR)
2AWG
(38mm
2
)
Stranded copper only
(600V/80 )℃
61.1Kg-cm
(53.03lb-in)
External control signal
terminals
24AWG~14AWG
(0.5mm
2
~2.0mm
2
)
Stranded copper only
(300V/80 )℃
5.1Kg-cm
(4.42lb-in)
