Deceleration time 2
2CH=OFF
2CH=ON
2CH=ON
2CH=OFF
F
(HZ)
Description 2CH
Acceleration time 1
OFF
Deceleration time 1
Acceleration time 2
ON
Deceleration time 2
To operate inverter with 2CH function, check to see CD42 or CD43=3.
2CH command inputs from FT1 or FT2 terminal.
Setting Range 0.1 ~ 6000.0SEC
Default Value 10.0SEC
Carrier frequency
CD27
Increase the carrier frequency would reduce motor noise but efficiency
might be decreased.
Reduce the carrier frequency would increase noise and reduce motor
current, than gain better efficiency.
AP2G3-337~375
AP4G3-337~3110
Setting Range 1.0~15.0K
Default Value 15.0K
AP2G3-3110~3220
AP4G3-3150~3220
Setting Range 1.0~10.0K
Default Value 10.0K
