54
Communicator
protocol
CD78
A. Date format
0 : 8,N,1 RTU (1 start bit+8 data bits+1 stop bit)
8,N,1 RTU (10-bit)(character frame in hexadecimal)
1 : 8,N,2 RTU (1 start bit+8 data bits+2 stop bit)
8,N,2 RTU (11-bit)(character frame in hexadecimal)
2 : 8,E,1 RTU (1 start bit+8data bits+1 Even bit+1 stop bit)
8,E,1 RTU (11-bit)(character frame in hexadecimal)
3 : 8,O,1 RTU (1 start bit+8data bits+1 Odd bit+1 stop bit)
8,O,1 RTU (11-bit)(character frame in hexadecimal)
4 : 8,N,1 ASCII (1 start bit+8data bits+1 stop bit)
8,N,1 ASCII (10-bit)(character frame in hexadecimal)
Start
bit
0 1 2 3 4 5 6 7
Stop
bit
Start
bit
0 1 2 3 4 5 6 7
Stop
bit
Stop
bit
Start
bit
0 1 2 3 4 5 6 7
Even
Parity
Stop
bit
Setting Range 0 ~ 7
Default Value 4
Start
bit
0 1 2 3 4 5 6 7
Odd
Parity
Stop
bit
Start
bit
0 1 2 3 4 5 6 7
Stop
bit
