Operating
1-1. Pannel
Action : (a) Press for forward / reverse operation.
Speed : (a) Using to change motor speed with 1HZ
increment step. or to select the digit for quick
setting and confirm by
Standby : (a) Press back to standby mode after trip or function
setting mode.
1-2. F306
Set CD13=1 and repower “ON”, operation same as 1-1 pannel.
1-3. RS485 communication control
Set CD13=2 and set CD74~CD78. (Refer to CD74~CD78).
Using 06H function write command to address 100(64H).
1 : CW, 2 : CCW, 3 : Stop, 4 : Clear fault.
1-4. Terminal control
Set CD12=1, writing refer to control circuit terminal wiring
digaram.
