Note 1 : The parameter values can be in integer and decimal. Each value
has different process to read and write.
Refer to 8-1 lists to find out the minimum unit and value range
for each parameter.
The following value processing description (Note2~3), each hexa
decimal value has 4 numbers. First two numbers are D4, last two
numbers are D5.
Note 2 : Processing integer number
Transfer value into hexadecimal value. The first two numbers
is D4 and the last two numbers is D5.
Ex. Speed=1710 rpm
1710(decimal)=06AE(hexadecimal)
D4=06H
D5=AEH
Computer command message AC drive response message
D6
# of data '0'
# of data '2'
30
D6
CD23 content '0'
CD23 content 'B'
30
32 42
count by word '2'
D7
CD23 content 'B'
CD23 content '8'
42
D7 LRC HI LRC HI 38
D8 LRC LO LRC LO D8 LRC HI LRC HI
END HI 0D D9 LRC LO LRC LO
END LO 0A END HI 0D
END LO 0A
※
